SOLAR RADAR SPEED SIGN

  • Signs manufactured to Australian Standards using 3M reflective material
  • Increase the visibility of the message and improve safety
  • Reduces the speed of traffic by creating awareness of speed limit
  • >72 hours autonomy, Day and/or night operation
  • IP65 Waterproof design
  • Quality LiFeP04 battery
  • Simple to install – secures to a 76mm sign post
  • Transportable trailer fixed option available
  • Efficient and effective visual enforcement
  • Doppler radar K-Band, 24.1250Ghz technology
  • Relocatable or Fixed versions available
  • 2 year warranty for faulty workmanship or component failure not influenced by external means.

Product

Solar
Lighting
Designs

Solar Lighting Designs

©2024

Product Description.

SOLAR RADAR SPEED SIGN

Radar speed signs provide positive visual enforcement of the designated speed limit. Usually installed in areas where speeding vehicles are in close proximity to pedestrians. The Solar Radar speed limit sign utilizes ultra-bright, high quality and long-life LED technology to provide an animated enforcement of the designated speed limit. The minimal current draw of the system is simply and effectively powered using solar energy. A Bluetooth APP (android) allows control over the full dot matrix display area to change the posted speed limit between 00 – 99 Km/h and system analysis. Once the speed is set the radar detects oncoming vehicles and displays the vehicle speed.

Technical Data

SKU
SRSS003
LED Screen
320 x 320mm
Sign
900 x 600 x 100mm
Display Colour
Red/Green
LED Wavelength
Red:620/Green:525
Luminance Density
≥6000cd/m2 Outdoor Highlighted
Viewing Angle
60°
Viewing Distance
1 – 200 Mtrs)
Speed Range
1 – 99 km/h
Fixed Sign Material
Aluminum/3M reflective
Radar Frequency
K-Band, 24.1250Ghz
Radar Range
1 – 150 Mtrs
Radar Accuracy
<±1Km/h
Battery Specifications
24 Ah 12v (288Wh) LiFeP04
Power Consumption
Max 11W Average ≤2W
Solar Panel
18v 60w
Autonomy
>48 Hours (setting dependent)
Recharge
< 6 Hours
Mounting Height
2 – 2.5 Mtrs
Display Brightness
Automatic Dimming
Waterproof Rating
IP65
Warranty Period
2 years

Video



Printable Data Sheets

SOLAR RADAR SPEED SIGN SPECIFICATION

Additional Information

WHAT IS A LUMEN?In simple terms, Lumens are a measure of the total amount of visible light from a lamp or light source. The higher the lumen rating, the “brighter” the lamp will work.FAMILIAR EXAMPLES

  • A typical 4 x D cell battery maglite will emit approx. 70 lumens
  • The average path light using 2-3 LEDs emits 15-18 lumens
  • A 25W incandescent globe emits approximately 160 lumens
